Full Computerized Double Cylinder Automatic Linking Socks Knitting Machine

F-601, 4 inches full computerized socks machine, is capable to weave one color at the same row. 7 connections of yam feeder in different colors can be operated in constant alternating knitting. Fully automatic socks making machine is convenient for maintenance and boasts stable performance, and high productivity, and adopts the Internet intelligent technology of cash to complete all the hosiery weaving, hosiery turning, sewing and other processes in one machine, which visualizes the production process. A worker can manage more than 30 automatic linking socks machines at the same time, reducing labor labor by more than 70%.

Technical feature:

1. Drumless, fully automatic electronic control system;

2. Electro-pneumatic yam finger, bolt cams control;

3. Ac servo motor and driver;

4. Products in a circle of 1 color, up to 6inter colors in total;

5. Reinforcement for heel&toe;

6. Various sensor for obstacles(yarn inlet, yarn cutting, defected needle, selector cutting, electric obstacle);

7. Automatic lubricant device;

8. Electronic-pneumatic cam, pick up and pick down;

9. Automatic turning over socks device;

10. "Y" or "W" forms of heel Part;

11. Socks separation to bottom direction and automatic turning over socks device; (This function can be used without toe closing device);

12. Independent automatic alignment head device.

Features of pattern design system:

1. Multiple languages displayed on LCD

2. USB system

3. High efficiency and precise actuator（8 steps）

4. Self-test function of actuator

5. Self-test function of each electric action part

6. Sole pattern selecting

7. Display of productivity

8. Storing of pattern design & style (Chain data)

Specifications:

Cylinder Diameter: 4 inches

Needle range: 108N~176N

Revolution: 260Rpm~320Rpm

Motor: 6.5Kw

Actuator: 5.5-6piezo electric ceramic actuators

Electric: 3P-AC 220V~380V 50/60Hz

Machine Dimension: (L)100cm X (W)160cm X (H)235cm

Packing Size: (L)120cm X (W)125cm X (H)200cm

Net weight: 500Kg

Gross Weight: 600Kg

*Production and R.P.M could be adjusted by different materials

Advantage:

1. High capacity

2. Less failure

3. Easy operation

4. Easy maintenance.

FAQ:

(1) Q: Are you a manufacturer or Trade Company?

A: We are a professional manufacturer holding our own International Trade Department, for that we can better understand customer's needs and offer a reasonable price.

(2) Q: Are you available for on-the-spot invitation?

A: We do welcome our new and old friends come here to have a visitation. Besides, we would send you our exposition and relative information to promote a face-to-face meeting if you'd like to.

(3) Q: Is the price offered changeable?

A: We offer reasonable price for every client, and the price is changeable according to purchasing amount.

(4) Q: How about the quality?

A: The main subassembly and raw materials are all supplied by large companies. Key parts are research and developed by our own staff. Professional assembly line work and strict quality test system can ensure your high quality requirement.

(5) Q: How's the after-sale service?

A: We offer engineers available to service overseas under merchandiser's supervision and translation.
